Specification

Viewing Head

Compensation free binocular head, 360° rotatable

Eyepiece

WF10X

Nosepiece

Quadruple

Objective

Achromatic 4X、10X、40X(s)、 100X(s, oil)

Stage

Double layer mechanical stage 115 x 125 mm

Condenser

N.A.1.25 Abbe condenser with iris diaphragm

Focusing

Coaxial coarse & fine focusing adjustment, focusing range 30 mm, focusing interval 0.002 mm

Light Source

AC Input 220V or 110V, DC Output 6V, Halogen bulb 6V/20W, adjustable brightness

Optional Accessory

Compensation free trinocular head,
Eyepiece：WF16X,
Objective：20X、60X（s）
