Specification

Viewing Head

Compensation free binocular head, inclined 30°, 360° rotatable

Eyepiece

WF10X, WF16X

Nosepiece

Quadruple

Objective

Achromatic 4X、10X、40X(s)、 100X(s, oil)

Stage

Double layer mechanical stage 180 x 150 mm

Condenser

N.A.1.25 Abbe condenser with iris diaphragm & filter

Focusing

Coaxial coarse & fine focusing adjustment with rack and pinion mechanism, fine focusing scale value 0.002 mm

Collector

High brightness Kohler illumination

Light Source

AC Input 220V or 110V, DC Output 12V, Halogen bulb 12V/20W, adjustable brightness

Optional Accessory

Compensation free trinocular head,
Eyepiece: WF 20X, and 1.3 Mega pixels CMSO electronic eyepiece, Quintuple nosepiece,
Objective：20X、60X（s), Semi-plan objectives: 4X、10X、 20X、40X(s)、60X（s)、100X(s, oil)， Infinity plan objectives: 4X、10X、 20X、40X(s)、60X（s)、100X(s, oil)
