Specification

Viewing Head

Compensation free binocular head, inclined 30°, 360° rotatable

Eyepiece

WF10X, WF16X

Nosepiece

Quintuple

Objective

Infinite plan achromatic: 4X、10X、20X、 40X(s)、 100X(s, oil)

Stage

Double layer mechanical stage 216 x 150 mm

Condenser

N.A.1.25 Abbe condenser with aperture diaphragm

Focusing

Coaxial coarse & fine focusing adjustment, fine focusing scale value 0.002 mm

Light Source

AC Input 220V or 110V, DC Output 12V, Halogen bulb 12V/20W, adjustable brightness

Optional Accessory

Compensation free trinocular head,
Eyepiece: WF 20X, and 1.3 Mega pixels modem digital eyepiece Quadruple nosepiece,
Infinity plan objectives: 60X（s), LED Illumination, Epi-fluorescent attachment
