Specification

Viewing Head

Compensation free binocular head, inclined 30°, 360° rotatable

Eyepiece

PL10X/20mm, or PL10X/22mm

Nosepiece

Quintuple

Objective

Infinitive plan achromatic: 4X、10X、 20X、40X(s)、 100X(s, oil)

Stage

Double layer mechanical stage 150 x 140 mm

Condenser

NA1.25 kohler illuminator condenser group (with socket for phase contrast, dark-filed device) & filter

Focusing

Coarse focusing scope is 30 mm, with tightness adjustment and place limit set, fine adjustment precision: 0.002 mm

Light Source

AC Input 220V or 110V, LED 3W Illumination, adjustable brightness

Optional Accessory

Compensation free trinocular head
Quadruple nosepiece,
Objective：infinity 60X（s), or Infinity semi-plan achromatic objectives: 4X、10X、 20X、40X(s)、60X（s)、100X(s, oil)
Halogen bulb 6V/30W
Dark – field accessories, phase contrast accessories, polarizer / analyzer
