Specification

Viewing Head

Dual viewing compensation free binocular head, inclined 30°, 360° rotatable

Eyepiece

WF10X/22mm

Nosepiece

Quadruple

Objective

Infinity achromatic 4X、10X、40X(s)、 100X(s, oil)

Stage

Double layer mechanical stage 180 x 150 mm

Condenser

N.A.1.25 Abbe condenser with iris diaphragm & filter

Focusing

Coaxial coarse & fine focusing adjustment, fine focusing scale value 0.002 mm

Collector

High brightness Kohler illumination

Light Source

AC Input 220V or 110V, DC Output 12V, Halogen bulb 12V/20W, adjustable brightness

Optional Accessory

Single compensation free binocular head,
Eyepiece: WF16X, WF 20X,
Quintuple nosepiece,
Objective：infinity 20X、60X（s),
Infinity plan objectives: 4X、10X、 20X、40X(s)、60X（s)、100X(s, oil)
