Specification

Viewing Head

Compensation free binocular head, inclined adjustment 0° - 40°, 360° rotatable

Eyepiece

WF10X / 22mm

Nosepiece

Quintuple

Objective

Infinity plan:4X、10X、40X(s)、60X(s)、100X(s, oil)

Stage

Double layer mechanical stage 180 x 160 mm

Condenser

Swing type NA1.25 Abbe condenser with iris diaphragm & filter

Focusing

Coaxial coarse & fine focusing adjustment with rack and pinion mechanism, fine focusing scale value 0.002 mm

Collector

High brightness Kohler illumination

Light Source

AC Input 220V or 110V, halogen bulb 12V/30W, or 12V/50W, or 12V/100W, adjustable brightness

Optional Accessory

Compensation free trinocular head, Eyepieces: WF16x, WF20x, WF25x, P16x,
Infinity objectives: 20X,
Fluorescent attachment,
Phase contrast attachment
Simple polarization attachment
3.0 or 1.3 Mega pixel CMOS electronic eyepiece
